Teradek Bolt 4K LT 750 3G-SDI/HDMI Wireless Transmitter and Receiver Kit

by Teradek
Sold Out
Original price $2,990.00 - Original price $2,990.00
Original price
$2,990.00
$2,990.00 - $2,990.00
Current price $2,990.00
SKU 67440
Minimum quantity allowed is .
Maximum quantity allowed is .
The product can be bought in quantity increments of .
Teradek Bolt 4k Lt 750 Tx/rx

Bolt 4K. Detail Matters.

Unlock New Wireless Functionality.
Fully-compatible ecosystem w/ more receivers.

Boost Your Signal Strength & Range.
Next-gen RF technology.

See Every Detail.
Wide-gamut wireless 4K HDR.

Take Control With Bolt 4K Mobile App.
Configure settings, monitor status, wirelessly pair units.

The Future Of Wireless Video.
Bolt 4K elevates the standard for all cable-free workflows. Incredible wireless image quality. Lossless real-time transmission. Enhanced detail with 4K HDR. More reliable, longer range, and a new mobile app for remote configuration.

Incredible Image Quality With More Range.
Bolt 4K transmits full HD and 4K video up to 5,000 ft. at less than 1 millisecond of delay, making it an invaluable tool for focus pullers, aerial cinematographers, gimbal operators, and those capturing tricky shots that only a Bolt system can carry out.

Our patented wireless technology produces jaw dropping, 10-bit image quality at every resolution up to DCI 4K, giving you a picture that is so detailed and color accurate that it is practically indistinguishable from an SDI cable.

Unmatched Reliability.

Bolt 4K operates over 13 certified 40MHz channels that give you more options to avoid interference than ever before. For particularly noisy environments, switch Bolt 4K into Fixed Frequency Mode to lock onto a designated 5GHz channel. We’ve also greatly improved communication between the TX and RX, resulting in better performance in challenging environments and instantaneous reconnection times.

Cinema Workflow.
On set, you want as many eyes on the shot as possible. With Bolt 4K, send video to up to 6x receivers so you can give the Director, DOP, AC, DIT and everyone on set the ability to monitor at any resolution up to DCI 4K.

True HDR Wireless Transmission.

Bolt 4K is compliant with the HLG, PQ, and HDR-10 standards, making it an invaluable tool on set for HDR workflows. Monitor your every shot in deep, brilliant colors with accurate highlights and lossless image quality, all in 10-bit and at resolutions of up to 2160p.

Manage Bolt From Your Smartphone.
With our free Bolt iOS/Android application, you can instantaneously pair your TX and RX, apply custom output settings to each RX, and manually set a 5GHz channel to operate on. We’ve also included a built in 5GHz Spectrum Analyzer, as well as a Wireless Health analysis tool so you can keep an eye on your environment to ensure you’re avoiding interference as much as possible.

Unbreakable Encryption.
Bolt 4K offers the industry’s best protection against prying eyes with AES-256 encryption and RSA 1024 key pairing. Combined, these two technologies ensure nobody can decrypt your wireless feed or connect another receiver to your system without explicit authorization

Universal Compatibility.
Flexibility on set is crucial, so we’ve designed Bolt 4K to be universally compatible with any 4K transmitter and receiver. That means a 750 model will transmit to a 1500, MAX and vice versa, all while retaining perfect image quality and any extended metadata.

Transmit To Multiple Receivers.
Our patented wireless technology allows Bolt 4K to transmit to more receivers simultaneously than previous systems without sacrificing image quality or reliability. Send a feed to the director, video village, clients, and more, with up to 6 receivers supported at the same time.

Extended Metadata & Camera Support.
Bolt 4K transmits more than just audio and video, it also sends start / stop flags, timecode, and other ancillary data over the wireless link. On the receiver side, you can upload and apply your own custom 3D LUTs to monitor each take with the look you’re after.

Glazer's SKU 67440
Manufacturer Teradek
MFG SKU 10-2200
Product Specs

Teradek LT 750 Specs

Wireless
Wireless Range 750' / 228.6 m (Line-of-Sight)
# of Channels 13 (40 MHz)
25 (20 MHz)
Channel Bandwidth 40 MHz, 20 MHz
Frequency Range Non-DFS Frequencies
US: 5.19 to 5.23 GHz
US: 5.75 to 5.79 GHz
DFS Frequencies
US: 5.27 to 5.67 GHz
Latency < 0.01 ms
RF Power 17 dBm
Wireless Video Compression Uncompressed
Interfaces
Transmitter Antenna Ports 2 x RP-SMA
Receiver Antenna Ports 5 x RP-SMA
Transmitter Video Connectors 1 x HDMI Input
1 x BNC (3G-SDI) Input
1 x BNC (3G-SDI) Loop Output
Receiver Video Connectors 1 x HDMI Output
1 x BNC (3G-SDI) Output
Transmitter Other I/O 1 x USB Micro-B Input
Receiver Other I/O 1 x USB Micro-B Input
Embedded Audio SDI: 2-Channel
HDMI: 2-Channel
Encryption 256-Bit AES
Format Support
Video Format SDI/BNC:
1080p 4:2:2 YCC 10-Bit at 23.98, 24, 25, 29.97, 30, 59.94, 60 fps
1080PsF 4:2:2 YCC 10-Bit at 23.98, 24, 25, 29.97, 30 fps
1080i/720p 4:2:2 YCC 10-Bit at 50, 59.94, 60 fps
576p at 25, 50 fps
576i at 50 fps
480p at 59.94, 60 fps
480i at 59.94 fps
HDMI:
UHD 4K 4:4:4 RGB 10-Bit at 23.98, 24, 25, 29.97, 30 fps
1080p 4:4:4 RGB 10-Bit at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
1080PsF 4:4:4 RGB 10-Bit at 23.98, 24, 25, 29.97, 30 fps
1080i/720p 4:4:4 RGB 10-Bit at 50, 59.94, 60 fps
576p at 25, 50 fps
576i at 50 fps
480p at 59.94, 60 fps
480i at 59.94 fps
Audio Format 2-Channel 24-Bit 48 kHz LPCM Audio
Timecode Yes
Display
Transmitter Panel Type OLED
Receiver Panel Type OLED
Power
Transmitter Built-In Battery None
Receiver Built-In Battery None
Transmitter Power Connector 1 x 2-Pin LEMO (6 to 28 VDC) Input
Receiver Power Connector 1 x 2-Pin LEMO (6 to 28 VDC) Input
Transmitter Power Consumption Device: (9 W)
Receiver Power Consumption Device: (11 W)
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
General
Transmitter Mounting 1 x 1/4"-20 Female
1 x M3 Female
Receiver Mounting 1 x 1/4"-20 Female
1 x M3 Female
Materials Aluminum, PCB
Transmitter Dimensions 4.1 x 2.4 x 1.3" / 103 x 60 x 33 mm
Receiver Dimensions 4.8 x 3.7 x 1.1" / 122 x 94 x 27 mm
Transmitter Weight 7.3 oz / 206 g
Receiver Weight 10.3 oz / 292 g
