Portkeys BM5 III 5.5" HDMI Touchscreen Monitor with Camera Control

Name: Portkeys BM5 III 5.5" HDMI Touchscreen Monitor with Camera Control
Brand: Portkeys
SKU: 90277
Price: 499.0 USD
Availability: InStock

by Portkeys

$0.00 - $0.00

$0.00

$499.00

$499.00 - $499.00

$499.00

SKU 90277

Minimum quantity allowed is .

Maximum quantity allowed is .

The product can be bought in quantity increments of .

Description
Additional Information

The BM5 III is a 5.5-inch monitor with wireless camera control, your loyal assistant to adjust proper exposure and sharp focus when capturing the images. This ultra-bright onboard monitor features a wide color gamut, a durable aluminum build, and both HDMI and 3G/SDI video inputs and SDI output.

Features:

5.5-inch 2200nit Super-Bright Monitor
Wide Color Gamut
New peaking algorithm captures more focus
Freeze Frame
High Precision Waveform
Image Capture and Overlay
Color Calibration
Milled Aluminum
Wired Camera Control/Wireless Camera Control
Control Tilta Motors and Cursor Display

In The Box:
1 x Portkeys BM5 III 5.5" HDMI Touchscreen Monitor with Camera Control
1 x Power Cord (Aviation Port - D-TAP)
1 x Power Cord (Aviation Port - DC)
1 x LANC Control Cable
1 x TYPE-C Control Cable
1 x Warm Prompt Card
1 x Customer Feedback Card
1 x U Disk(Manual, 3D LUTS, Firmware Inside)
1 x Safety Box

Glazer's SKU

90277

Manufacturer

Portkeys

MFG SKU

PKS1005

Product Specs

Specifications:

Screen Size	5.5"
Dimension	145.4×91.4×37.75mm
Viewing Angle	178°H/178°V
Brightness	2200nit
Resolution	1920×1080
Contrast Ratio	1000:1
Weight	351g
Color Depth	10bit (8+2FRC)
Backlight	WLED
Material	Aluminum alloy +Toughened glass
Input Voltage	4pin Aviation Connector IN 7.4 -24V
Output Voltage	4pin Aviation Connector OUT 7.4V (NPF)
Maximum Power	13W
Video Signal Input	SDI, HDMI
Video Signal Output	SDI
Motor Control Port	5pin Aviation Connector
Camera Control Port	Mini USB 10pin
USB-A	Upgrade Firmware / Load LUT

Format Support:

Video Format

HDMI
1920×1080p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz,50 Hz, 59.94Hz,60Hz

1920×1080psf@23.97Hz,24Hz,25Hz,29.97Hz,30Hz

1920 × 1080@50Hz,59.94Hz,60Hz

1280 × 720p@50Hz,59.94Hz, 60H

720×576@50H

720×576p@50Hz

720×480p@59.94Hz,60Hz

720×480@59.94Hz,60HZ

SDI Signal

1920X1080p@50fps,59.94fps,60fps

1920 × 1080p@50Hz,59.94Hz,60Hz YUV422

1920 × 1080p@23.98Hz,24Hz,25Hz, 29.94Hz,30Hz

YUV444/YUV422/RGB444

1920 × 1080psf@23.98Hz,24Hz,25Hz,29.97 Hz,30Hz

YUV444/YUV422/RGB444

1920×1080@50Hz,59.94Hz,60Hz YUV444/YUV422/ RGB444

1280×720р @50Hz,59.94Hz,60Hz YUV444/YUV422/ RGB444

Software Function:

Software Function

3D LUT
Waveform
New Peaking
Histogram
Camera Control
Image Capture
Image Overlay
BMD SDI TALLY
Guides
HLG
Zebra
Check Field
Grids
Audio Meters
Tint
Backlight
Fan Adjustable
Rectangle Crop
Anamorphic
1080p to 1080i
HDMI to SDI Output
Cross Hair
Osd Flip
False Color
H/V Delay
Aspect
Custom RGB
Sharpness
Chroma
Brightness
Contrast
UnderScan
3D LUT SDI Output
Battery (Level) Display
Power to Camera by Dummy Battery
Image Flip Automatically/Manually
